| PartNumber | B116XTB01.0 |
| Značka | AUO |
| Velikost | 11.6 |
| aplikace | NBPC |
| Rozlišení | 1366×768 |
| Složení | Assembly |
| Jas | 200 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | AUO |
| panelový model | B116XTB01.0 |
| typ panelu | a-Si TFT-LCD , Assembly |
| velikost panelu | 11.6 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| aktivní oblast | 256.13×144 mm |
| obrys | 284.1×185×4.2 mm |
| tvarový styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| povrch | Hard coating (3H) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193145% |
| úhel pohledu | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | eDP (1 Lane), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| B116XTB01.0 | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW5A | AUO | 11.6 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| B116XW01 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V1 | AUO | 11.6 | 1366×768 |
| B116XW03 V0 | AUO | 11.6 | 1366×768 |
| B116XW05 V0 | AUO | 11.6 | 1366×768 |
| B116XW05 V001 | AUO | 11.6 | 1366×768 |
| B156HW01 V4 | AUO | 15.6 | 1920×1080 |
| FLC31SVC6S-17 | Fujitsu | 12.1 | 800×600 |
| LP140WH1-TLE2 | LG Display | 14.0 | 1366×768 |
| LP173WD1-TLG2 | LG Display | 17.3 | 1600×900 |
| LTN140AT04-G01 | Samsung | 14.0 | 1366×768 |
| LTN150XB-L02 | Samsung | 15.0 | 1024×768 |
| LTN156AT05-701 | Samsung | 15.6 | 1366×768 |
| LTN160AT01-W01 | Samsung | 16.0 | 1366×768 |
| LTN184HT05-D01 | Samsung | 18.4 | 1920×1080 |
| N140BGE-L33 | Innolux | 14.0 | 1366×768 |
