| PartNumber | B125HAN02.2 |
| Značka | AUO |
| Velikost | 12.5 |
| aplikace | NBPC |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 300 |
| CR | 700:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | AUO |
| panelový model | B125HAN02.2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 12.5 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | AHVA, Normally Black, Transmissive |
| aktivní oblast | 276.48×155.52 mm |
| obrys | 282.4×179.32×2.5 mm |
| tvarový styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | eDP (2 Lanes), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| B125HAN01.0 | AUO | 12.5 | 1920×1080 |
| B125HAN02.0 | AUO | 12.5 | 1920×1080 |
| B125HAN02.2 | AUO | 12.5 | 1920×1080 |
| B125XW01 V0 | AUO | 12.5 | 1366×768 |
| HB125WX1-100 | BOE | 12.5 | 1366×768 |
| LP125WF1-SPD1 | LG Display | 12.5 | 1920×1080 |
| LP125WF2-SPB3 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LTN125AT03-803 | Samsung | 12.5 | 1366×768 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| B133XW04 V0 | AUO | 13.3 | 1366×768 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM2 | LG Display | 14.0 | 1366×768 |
| LTN140AT21-T01 | Samsung | 14.0 | 1366×768 |
| LTN141XF-L03 | Samsung | 14.1 | 1024×768 |
| LTN156KT01-W01 | Samsung | 15.6 | 1600×900 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
