| PartNumber | B133EW06 V0 |
| Značka | AUO |
| Velikost | 13.3 |
| aplikace | NBPC |
| Rozlišení | 1280×800 |
| Složení | LCM |
| Jas | 200 |
| CR | 600:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | B133EW06 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 13.3 inch |
| rozlišení | 1280(RGB)×800 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 286.08×178.8 mm |
| obrys | 304×203×3.5 mm |
| tvarový styl | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193145% |
| Doba odezvy | 4/12 (Typ.)(Tr/Td) |
| úhel pohledu | 40/40/15/25 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 9S6PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| B133EW01 V0 | AUO | 13.3 | 1280×800 |
| B133EW03 V0 | AUO | 13.3 | 1280×800 |
| B133EW03 V1 | AUO | 13.3 | 1280×800 |
| B133EW03 V2 | AUO | 13.3 | 1280×800 |
| B133EW04 V0 | AUO | 13.3 | 1280×800 |
| B133EW04 V4 | AUO | 13.3 | 1280×800 |
| B133EW05 V0 | AUO | 13.3 | 1280×800 |
| B133EW06 V0 | AUO | 13.3 | 1280×800 |
| B133EW07 V1 | AUO | 13.3 | 1280×800 |
| B133EW07 V2 | AUO | 13.3 | 1280×800 |
| B156HAT01.0 | AUO | 15.6 | 1920×1080 |
| BT140GW03 V.2 | Innolux | 14.0 | 1366×768 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP150X08-A3 | LG Display | 15.0 | 1024×768 |
| LP156WD1-TLB4 | LG Display | 15.6 | 1600×900 |
| LP156WH2-TLB1 | LG Display | 15.6 | 1366×768 |
| LTN156AT36-W01 | Samsung | 15.6 | 1366×768 |
| LTN156HL01 | Samsung | 15.6 | 1920×1080 |
| M101NWN8 R0 | IVO | 10.1 | 1366×768 |
| N121IB-L06 | Innolux | 12.1 | 1280×800 |
