| PartNumber | B154SW02 V0 |
| Značka | AUO |
| Velikost | 15.4 |
| aplikace | NBPC |
| Rozlišení | 1680×1050 |
| Složení | LCM |
| Jas | 330 |
| CR | 800:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | B154SW02 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.4 inch |
| rozlišení | 1680(RGB)×1050 , WSXGA+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 331.38×207.11 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 330 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193172% |
| Doba odezvy | 12/4 (Typ.)(Tr/Td) |
| úhel pohledu | 35/35/30/30 (Typ.)(CR≥100)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLED |
| signálové rozhraní | LVDS (2 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
