| PartNumber | B201SW01 V0 |
| Značka | AUO |
| Velikost | 20.1 |
| aplikace | NBPC |
| Rozlišení | 1680×1050 |
| Složení | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | B201SW01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 20.1 inch |
| rozlišení | 1680(RGB)×1050 , WSXGA+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 433.44×270.9 mm |
| obrys | 453.5×296.5 mm |
| povrch | Glare (Haze 0%), Hard coating (3H), Reflection 4.5% (Max.) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC) |
| Doba odezvy | 3.8/1.2 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 40 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | NBPC |
| B201SW01 V0 | AUO | 20.1 | 1680×1050 |
| HT201V01-101 | BOE | 20.1 | 640×480 |
| LM201U02-A3C3 | LG Display | 20.1 | 1600×1200 |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201WE3-TLJ3 | LG Display | 20.1 | 1680×1050 |
| LQ201U1LW31 | SHARP | 20.1 | 1600×1200 |
| LTM201M2-L02 | Samsung | 20.1 | 1680×1050 |
| LTM201U1-L01 | Samsung | 20.1 | 1600×1200 |
| M201EW01 V3 | AUO | 20.1 | 1680×1050 |
| M201EW02 V9 | AUO | 20.1 | 1680×1050 |
| LP133WP1-TJA1 | LG Display | 13.3 | 1440×900 |
| LP156WD1-TPB1 | LG Display | 15.6 | 1600×900 |
| LP156WF1-TLF4 | LG Display | 15.6 | 1920×1080 |
| LTD121EXSS | TOSHIBA | 12.1 | 1280×800 |
| LTM10C348P | TOSHIBA | 10.4 | 800×600 |
| LTN150PF-L03 | Samsung | 15.0 | 1400×1050 |
| LTN184KT01-S02 | Samsung | 18.4 | 1680×945 |
| M125NWR2 R1 | IVO | 12.5 | 1366×768 |
| N141XC-L02 | Innolux | 14.1 | 1024×768 |
| QD15XL06 Rev.01 | QDI | 15.0 | 1024×768 |
