| PartNumber | BRS550H2 |
| Značka | BERISE |
| Velikost | 55 |
| aplikace | PID |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 2000 |
| CR | 1200:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | BERISE |
| panelový model | BRS550H2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 55 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 1209.6×680.4 mm |
| obrys | 1240.9×717.2×40.8 mm |
| povrch | Antiglare (Haze 1%), Hard coating (3H) |
| jas | 2000 cd/m² (Typ.) |
| kontrastní poměr | 1200:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193168% |
| Doba odezvy | 6 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 51 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | PID |
