| PartNumber | EL640.480-AA1 |
| Značka | Lumineq |
| Velikost | 10.4 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | EL |
| Jas | 20 |
| CR | 10:1 |
| Barvy | 8 |
| Podsvícení | self |
| Rozhraní | Parallel Data |
| značka panelu | Lumineq |
| panelový model | EL640.480-AA1 |
| typ panelu | EL , EL |
| velikost panelu | 10.4 inch |
| rozlišení | 640(RG)×480 , VGA |
| aktivní oblast | 211.1×158.3 mm |
| obrys | 263×205 mm |
| povrch | |
| jas | 20 cd/m² (Typ.) |
| kontrastní poměr | 10 : 1 (Typ.) |
| zobrazit barvy | 8 (3-bit) |
| úhel pohledu | 70/70/70/70 (Typ.)(L/R/U/D) |
| signálové rozhraní | Parallel Data (4-bit), 40 pins |
| vstupní napětí | 5.0/12.0V (Typ.)(VCC1/VCC2) |
| aplikace | IA |
