| PartNumber | H466TAN01.1 |
| Značka | AUO |
| Velikost | 4.7 |
| aplikace | MPH |
| Rozlišení | 720×1280 |
| Složení | CELL |
| Jas | 0 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | No B/L |
| Rozhraní | |
| značka panelu | AUO |
| panelový model | H466TAN01.1 |
| typ panelu | LTPS TFT-LCD , CELL |
| velikost panelu | 4.7 inch |
| rozlišení | 720(RGB)×1280 , WXGA |
| zobrazovací mód | AHVA, Normally Black, Transmissive |
| aktivní oblast | 58.104×103.296 mm |
| obrys | 60.9×111.87 mm |
| povrch | Hard coating |
| hloubka skla | 0.17+0.17 mm |
| propustnost | 3.9% (Typ.)(with Polarizer) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193166% |
| Doba odezvy | 35 (Max.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| řidič ic | COG Built-in NT35590 |
| aplikace | MPH |
