| PartNumber | HV460WU2-202 |
| Značka | BOE |
| Velikost | 46 |
| aplikace | LCTV |
| Rozlišení | 1920×1080 |
| Složení | CELL |
| Jas | 0 |
| CR | 1200:1 |
| Barvy | 16.7M |
| Podsvícení | No B/L |
| Rozhraní | LVDS |
| značka panelu | BOE |
| panelový model | HV460WU2-202 |
| typ panelu | a-Si TFT-LCD , CELL |
| velikost panelu | 46 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | ADS, Normally Black, Transmissive |
| aktivní oblast | 1018.08×572.67 mm |
| obrys | 1039.1×590.7 mm |
| povrch | Antiglare (Haze 10%), Hard coating (3H) |
| hloubka skla | 0.70+0.70 mm |
| propustnost | 6.2% (Typ.)(with Polarizer) |
| kontrastní poměr | 1200:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 8 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | LVDS (2 ch, 8-bit), 51 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
