| PartNumber | HV550WUP-200 |
| Značka | BOE |
| Velikost | 55 |
| aplikace | LCTV |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 360 |
| CR | 1400:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | BOE |
| panelový model | HV550WUP-200 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 55 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | ADS, Normally Black, Transmissive |
| aktivní oblast | 1209.6×680.4 mm |
| obrys | 1237.4×717.3 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 360 cd/m² (Typ.) |
| kontrastní poměr | 1400:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 8 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 10-bit), 51 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
| HV550WU2-370 | BOE | 55 | 1920×1080 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550DUS-SCM3 | LG Display | 55 | 1920×1080 |
| LC550EUD-FFF1 | LG Display | 55 | 1920×1080 |
| LC550EUE-SEM1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PEF1 | LG Display | 55 | 1920×1080 |
| LD550DUS-SEF1 | LG Display | 55 | 1920×1080 |
| LTI550FN01 | Samsung | 55 | 3840×2160 |
| ST5461B03-1 | CSOT | 55 | 1920×1080 |
| ST5461D01-1 | CSOT | 55 | 3840×2160 |
| LC420EUD-SDF1 | LG Display | 42 | 1920×1080 |
| LC420EUN-FFM1 | LG Display | 42 | 1920×1080 |
| LC430DUY-SHA1 | LG Display | 43 | 1920×1080 |
| LTA460WT-L14 | Samsung | 46 | 1366×768 |
| T320HVN02.0 CELL | AUO | 31.5 | 1920×1080 |
| T420HW01 V2 | AUO | 42 | 1920×1080 |
| T420HW09 V1 | AUO | 42 | 1920×1080 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
| V420H1-LH4 | Innolux | 42 | 1920×1080 |
| V850DK1-KD1 Rev.J2 | Innolux | 85 | 3840×2160 |
