| PartNumber | LB058WQ1-SD01 |
| Značka | LG Display |
| Velikost | 5.8 |
| aplikace | CNS |
| Rozlišení | 400×240 |
| Složení | LCM |
| Jas | 470 |
| CR | 630:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | LG Display |
| panelový model | LB058WQ1-SD01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.8 inch |
| rozlišení | 400(RGB)×240 , WQVGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 126.36×75.84 mm |
| obrys | 152×97 mm |
| povrch | Antiglare, Antireflection |
| jas | 470 cd/m² (Min.) |
| kontrastní poměr | 630:1 (Min.) |
| zobrazit barvy | 262K (6-bit), CIE193160% |
| Doba odezvy | 15/14 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/30/40 (Typ.)(CR≥100)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S3PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | CNS |
| CLAF058LA31 | CPT | 5.8 | 540×960 |
| DMC-40202NY-LY-ARE-AZN | Kyocera | 5.8 | 40×2 |
| LA058WQ1-SD01 | LG Display | 5.8 | 400×240 |
| LB058WQ1-SD01 | LG Display | 5.8 | 400×240 |
| LB058WQ1-SD02 | LG Display | 5.8 | 400×240 |
| LB058WQ1-SD03 | LG Display | 5.8 | 400×240 |
| LQ058T5DG30 | SHARP | 5.8 | 480×240 |
| PM058OX1 | E Ink | 5.8 | 1280×768 |
| TM058WA-22L03 | SANYO | 5.8 | 400×234 |
| TX15D02VM0CAA | KOE | 5.8 | 400×240 |
| 70WVW1T | SII | 7.0 | 800×480 |
| 70WVW2A | SII | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| G080Y1-T01 | Innolux | 8.0 | 800×480 |
| LQ049B5DG02 | SHARP | 4.9 | 320×96 |
| LQ070Y5DR04 | SHARP | 7.0 | 800×480 |
| LQ5AW136R | SHARP | 5.0 | 320×234 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| YX050800480WTIPS | 5.0 | 800×480 |
