| PartNumber | LM215WF5-SLA1 |
| Značka | LG Display |
| Velikost | 21.5 |
| aplikace | DMPC |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | LG Display |
| panelový model | LM215WF5-SLA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 21.5 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | e-IPS, Normally Black, Transmissive |
| aktivní oblast | 475.2×267.3 mm |
| obrys | 496.6×293.2×21 mm |
| povrch | Antiglare, Hard coating (4H) |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193171% |
| Doba odezvy | 14 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | DMPC |
| LM215WF1-TLA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF1-TLE1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SDC2 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLA2 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLD1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLA3 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLE7 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM190E05-SL03 | LG Display | 19.0 | 1280×1024 |
| LM190E08-TLJ7 | LG Display | 19.0 | 1280×1024 |
| LM250WW1-SSA1 | LG Display | 25.0 | 2560×1080 |
| LM300WQ6-SLA1 | LG Display | 30.0 | 2560×1600 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| M236HGE-L20 | Innolux | 23.6 | 1920×1080 |
| M236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| M270HVN02.0 | AUO | 27.0 | 1920×1080 |
| MT230DW01 V.0 | Innolux | 23.0 | 1920×1080 |
