| PartNumber | LP079X01-SMA1 |
| Značka | LG Display |
| Velikost | 7.9 |
| aplikace | PAD |
| Rozlišení | 768×1024 |
| Složení | LCM |
| Jas | 425 |
| CR | 900:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | LG Display |
| panelový model | LP079X01-SMA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.9 inch |
| rozlišení | 768(RGB)×1024 , XGA |
| zobrazovací mód | AH-IPS, Normally Black, Transmissive |
| aktivní oblast | 119.808×159.744 mm |
| obrys | 129×171.07×4.81 mm |
| povrch | Glare (Haze 0%), Hard coating |
| jas | 425 cd/m² (Typ.) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 17 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6 stringsWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 32 pins |
| vstupní napětí | 3.6V (Typ.) |
| aplikace | PAD |
