| PartNumber | LQ10PX01 |
| Značka | SHARP |
| Velikost | 10.4 |
| aplikace | PRO |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 0 |
| CR | 60:1 |
| Barvy | 262K |
| Podsvícení | No B/L |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ10PX01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 211.968×158.976 mm |
| obrys | 283×215.6 mm |
| povrch | |
| jas | 0 cd/m² |
| kontrastní poměr | 60:1 (Min.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 30/50 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/30/10 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | No B/L |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 36 pins |
| vstupní napětí | 5.0/12.0V (Typ.)(VCC/VDD) |
| aplikace | PRO |
