| PartNumber | LTA400HF09 |
| Značka | Samsung |
| Velikost | 40 |
| aplikace | LCTV |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 450 |
| CR | 5000:1 |
| Barvy | 1.07B |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SAMSUNG |
| panelový model | LTA400HF09 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 40 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | S-PVA, Normally Black, Transmissive |
| aktivní oblast | 885.6×498.15 mm |
| obrys | 952×551 mm |
| povrch | Antiglare (Haze 4.5%) |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 5000:1 (Typ.) |
| zobrazit barvy | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 6 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 12 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (4 ch, 10-bit), 92 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
