| PartNumber | LTM236FL01 |
| Značka | Samsung |
| Velikost | 23.6 |
| aplikace | DMPC |
| Rozlišení | 3840×2160 |
| Složení | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | SAMSUNG |
| panelový model | LTM236FL01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 23.6 inch |
| rozlišení | 3840(RGB)×2160 , UHD |
| zobrazovací mód | PLS, Normally Black, Transmissive |
| aktivní oblast | 521.28×293.22 mm |
| obrys | 544.8×320.5×11 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), sRGB100% |
| Doba odezvy | 14 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 stringsWLEDWithout Driver |
| signálové rozhraní | eDP (4 Lanes), 51 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
