| PartNumber | LTN156FL02-L01 |
| Značka | Samsung |
| Velikost | 15.6 |
| aplikace | NBPC |
| Rozlišení | 3840×2160 |
| Složení | LCM |
| Jas | 270 |
| CR | 700:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | SAMSUNG |
| panelový model | LTN156FL02-L01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.6 inch |
| rozlišení | 3840RG(BW)×2160 , UHD |
| zobrazovací mód | PLS, Normally Black, Transmissive |
| aktivní oblast | 344.448×193.752 mm |
| obrys | 359.5×223.8×3 mm |
| tvarový styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| povrch | Glare (Haze 0%) |
| jas | 270 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4S10PWLEDEmbedded (LED Driver) |
| signálové rozhraní | eDP (4 Lanes), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
