| PartNumber | LTN170CT08-L01 |
| Značka | Samsung |
| Velikost | 17.0 |
| aplikace | NBPC |
| Rozlišení | 1920×1200 |
| Složení | LCM |
| Jas | 280 |
| CR | 600:1 |
| Barvy | 16.7M |
| Podsvícení | RGB LED |
| Rozhraní | LVDS |
| značka panelu | SAMSUNG |
| panelový model | LTN170CT08-L01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1920(RGB)×1200 , WUXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 367.2×229.5 mm |
| obrys | 382.2×247.5×7 mm |
| tvarový styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Antiglare (Haze 40%), Hard coating (3H) |
| jas | 280 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE1931110% |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | RGB LEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
