| PartNumber | M116NWR1 R1 |
| Značka | IVO |
| Velikost | 11.6 |
| aplikace | NBPC |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 220 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | IVO |
| panelový model | M116NWR1 R1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 11.6 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 256.125×144 mm |
| obrys | 278×167×3.7 mm |
| tvarový styl | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| povrch | Antiglare |
| jas | 220 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193145% |
| Doba odezvy | 8 (Typ.)(Tr+Td) |
| úhel pohledu | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| HN116WX1-100 | BOE | 11.6 | 1366×768 |
| LP116WH1-TLA1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R0 | IVO | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| M116NWR4 R0 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116BGE-L11 | Innolux | 11.6 | 1366×768 |
| N116HSE-EA1 | Innolux | 11.6 | 1920×1080 |
| B154EW01 V3 | AUO | 15.4 | 1280×800 |
| B156XW02 V2 HW4A | AUO | 15.6 | 1366×768 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| LP133WH1-TLA2 | LG Display | 13.3 | 1366×768 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP173WF2-TPB1 | LG Display | 17.3 | 1920×1080 |
| LTN140KT13-B01 | Samsung | 14.0 | 1600×900 |
| LTN154X3-L01 | Samsung | 15.4 | 1280×800 |
| NV125QUM-N81 | BOE | 12.5 | 3840×2160 |
| NV133FHM-N52 | BOE | 13.3 | 1920×1080 |
