| PartNumber | M150EW01 V0 |
| Značka | AUO |
| Velikost | 15.0 |
| aplikace | DMPC |
| Rozlišení | 1280×720 |
| Složení | LCM |
| Jas | 200 |
| CR | 400:1 |
| Barvy | 16.7M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | M150EW01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.0 inch |
| rozlišení | 1280(RGB)×720 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 332.16×186.84 mm |
| obrys | 354.1×227.4 mm |
| povrch | Antiglare |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193145% |
| Doba odezvy | 5/3 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | DMPC |
