| PartNumber | N156O6-L01 |
| Značka | Innolux |
| Velikost | 15.6 |
| aplikace | NBPC |
| Rozlišení | 1600×900 |
| Složení | LCM |
| Jas | 220 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CMO |
| panelový model | N156O6-L01 10 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.6 inch |
| rozlišení | 1600(RGB)×900 , HD+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 344.16×193.59 mm |
| obrys | 359.3×209.5×5.5 mm |
| tvarový styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Antiglare, Hard coating (3H) |
| jas | 220 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193156% |
| Doba odezvy | 3/5 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 10S6PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| B156XTN02.0 | AUO | 15.6 | 1366×768 |
| B156XW01 V1 | AUO | 15.6 | 1366×768 |
| B156XW04 V5 | AUO | 15.6 | 1366×768 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| LQ156D1JX01 | SHARP | 15.6 | 3840×2160 |
| LTN156AT02-D04 | Samsung | 15.6 | 1366×768 |
| N156B6-L0B | Innolux | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
| B133HAT02.5 | AUO | 13.3 | 1920×1080 |
| B133XTN01.2 | AUO | 13.3 | 1366×768 |
| B141PW04 V0 HW2A | AUO | 14.1 | 1440×900 |
| HB140WX1-301 | BOE | 14.0 | 1366×768 |
| LM12S389 | SHARP | 12.1 | 800×600 |
| LP140WH2-TLN1 | LG Display | 14.0 | 1366×768 |
| LTN121AT10-301 | Samsung | 12.1 | 1280×800 |
| LTN121W1-L03 | Samsung | 12.1 | 1280×800 |
| LTN156AT35-W02 | Samsung | 15.6 | 1366×768 |
| N121IA-L02 | Innolux | 12.1 | 1280×800 |
