| PartNumber | PM062HT1 |
| Značka | E Ink |
| Velikost | 6.2 |
| aplikace | IA |
| Rozlišení | 640×240 |
| Složení | LCM |
| Jas | 280 |
| CR | 600:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | PVI |
| panelový model | PM062HT1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 6.2 inch |
| rozlišení | 640(RGB)×240 , HVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 148.8×53.76 mm |
| obrys | 173×70×8.9 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 280 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 15/25 (Typ.)(Tr/Td) |
| úhel pohledu | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
