| PartNumber | S50HW-YB06 |
| Značka | Samsung |
| Velikost | 50 |
| aplikace | LCTV |
| Rozlišení | 1365×768 |
| Složení | PDP |
| Jas | 630 |
| CR | 5000:1 |
| Barvy | 1.07B |
| Podsvícení | self |
| Rozhraní | LVDS |
| značka panelu | SAMSUNG SDI |
| panelový model | S50HW-YB06 |
| typ panelu | PDP , PDP |
| velikost panelu | 50 inch |
| rozlišení | 1365(RGB)×768 , WXGA |
| aktivní oblast | 1105.65×622.08 mm |
| obrys | 1175.4×688 mm |
| povrch | |
| jas | 630 cd/m² (Typ.) |
| kontrastní poměr | 5000 : 1 (Typ.) |
| zobrazit barvy | 1.07B (10-bit) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | LVDS (1 ch, 10-bit) + SPI, 30 pins |
| rohs: | |
| aplikace | LCTV |
