| PartNumber | T460HW04 V6 |
| Značka | AUO |
| Velikost | 46 |
| aplikace | LCTV |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 400 |
| CR | 4000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | T460HW04 V6 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 46 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | AMVA3, Normally Black, Transmissive |
| aktivní oblast | 1018.08×572.67 mm |
| obrys | 1076.5×634.7 mm |
| povrch | Antiglare (Haze 11%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 4000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 8.0 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 51 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
| T460HB01 V0 | AUO | 46 | 1920×1080 |
| T460HW03 VB | AUO | 46 | 1920×1080 |
| T460HW03 VF | AUO | 46 | 1920×1080 |
| T460HW03 VJ | AUO | 46 | 1920×1080 |
| T460HW04 V0 | AUO | 46 | 1920×1080 |
| T460HW04 V5 | AUO | 46 | 1920×1080 |
| T460HW07 V4 | AUO | 46 | 1920×1080 |
| T460HW07 V5 | AUO | 46 | 1920×1080 |
| T460HW08 V5 | AUO | 46 | 1920×1080 |
| T460HW08 VC | AUO | 46 | 1920×1080 |
| A201SN02 V5 | AUO | 20.1 | 800×600 |
| HT260WX1-100 | BOE | 26.0 | 1366×768 |
| LC420DUK-SGK2 | LG Display | 42 | 1920×1080 |
| LC420EUJ-SFK2 | LG Display | 42 | 1920×1080 |
| LTA460HT-L04 | Samsung | 46 | 1920×1080 |
| LTY460JN12 | Other | 46 | 1920×1080 |
| T260XW02 VK | AUO | 26.0 | 1366×768 |
| T260XW04 V7 | AUO | 26.0 | 1366×768 |
| T315HW07 VE | AUO | 31.5 | 1920×1080 |
| T650QVJ02.0 | AUO | 65 | 3840×2160 |
