| PartNumber | T470HVD01.1 |
| Značka | AUO |
| Velikost | 47 |
| aplikace | LCTV |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 350 |
| CR | 3000:1 |
| Barvy | 1.07B |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | T470HVD01.1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 47 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | AMVA, Normally Black, Transmissive |
| aktivní oblast | 1039.68×584.82 mm |
| obrys | 1070.6×622 mm |
| povrch | Antiglare (Haze 10%), Hard coating (2H) |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 3000:1 (Typ.) |
| zobrazit barvy | 1.07B (10-bit), CIE193172% |
| Doba odezvy | 5.5 (Typ.)(G to G) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 120Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (4 ch, 10-bit), 92 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
