| PartNumber | TX39D80VC1GAA |
| Značka | KOE |
| Velikost | 15.4 |
| aplikace | NBPC |
| Rozlišení | 1280×800 |
| Složení | LCM |
| Jas | 480 |
| CR | 600:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | HITACHI |
| panelový model | TX39D80VC1GAA |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.4 inch |
| rozlišení | 1280(RGB)×800 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 331.2×207 mm |
| obrys | 344×225 mm |
| povrch | Glare (Haze 0%) |
| jas | 480 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Min.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 50 (Typ.)(Tr+Td) |
| úhel pohledu | |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 6-bit) |
| vstupní napětí | 3.3V (Typ.) |
| rohs: | |
| aplikace | NBPC |
