| PartNumber | V580HK1-LD6 |
| Značka | Innolux |
| Velikost | 58 |
| aplikace | LCTV |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 350 |
| CR | 4000:1 |
| Barvy | 1.07B |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | V580HK1-LD6 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 58 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | Super MVA, Normally Black, Transmissive |
| aktivní oblast | 1270.08×721.44 mm |
| obrys | 1290.3×744.7×63.6 mm |
| povrch | Antiglare (Haze 1%) |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 4000:1 (Typ.) |
| zobrazit barvy | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 6.5 (Typ.)(G to G) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvence | 120Hz |
| typ lampy | 5 stringsWLEDWithout Driver |
| signálové rozhraní | LVDS (4 ch, 10-bit), 92 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | LCTV |
| V580DJ2-QS5 | Innolux | 58 | 3840×2160 |
| V580DK1-LS1 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 Rev.C8 | Innolux | 58 | 3840×2160 |
| V580DK2-LD1 | Innolux | 58 | 3840×2160 |
| V580HJ1-LD6 | Innolux | 58 | 1920×1080 |
| V580HJ1-LE6 | Innolux | 58 | 1920×1080 |
| V580HJ1-PD6 | Innolux | 58 | 1920×1080 |
| V580HK1-LD6 | Innolux | 58 | 1920×1080 |
| V580HK1-LE6 | Innolux | 58 | 1920×1080 |
| V580HK1-LS6 | Innolux | 58 | 1920×1080 |
| LC185EXN-SCA1 | LG Display | 18.5 | 1366×768 |
| LC320EXN-FEP1 | LG Display | 31.5 | 1366×768 |
| LC420WUF-SBN1 | LG Display | 42 | 1920×1080 |
| LC550EQD-FGF4 | LG Display | 55 | 3840×2160 |
| ST4851D01-2 | CSOT | 49 | 3840×2160 |
| T240HW01 V0 | AUO | 24.0 | 1920×1080 |
| T315XW03 VD | AUO | 31.5 | 1366×768 |
| T420HW04 V3 | AUO | 42 | 1920×1080 |
| T420HW05 V3 | AUO | 42 | 1920×1080 |
| T500DB01 V0 | AUO | 50 | 2560×1080 |
