| PartNumber | A050VW02 V0 |
| Značka | AUO |
| Velikost | 5.0 |
| aplikace | PND |
| Rozlišení | 480×800 |
| Složení | LCM |
| Jas | 450 |
| CR | 800:1 |
| Barvy | 16.2M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | AUO |
| panelový model | A050VW02 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 480(RGB)×800 , WVGA |
| zobrazovací mód | MVA, Normally Black, Transmissive |
| aktivní oblast | 64.8×108 mm |
| obrys | 68.8×117.1×2.81 mm |
| povrch | |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193150% |
| Doba odezvy | 20/15 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S2PWLEDWithout Driver |
| signálové rozhraní | MIPI (2 data lanes), 30 pins |
| vstupní napětí | 2.8/2.8V (Typ.)(VCI/VDDI) |
| aplikace | PND |
