| PartNumber | B080EAN01.1 |
| Značka | AUO |
| Velikost | 8.0 |
| aplikace | PAD |
| Rozlišení | 800×1280 |
| Složení | LCM |
| Jas | 400 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | AUO |
| panelový model | B080EAN01.1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.0 inch |
| rozlišení | 800(RGB)×1280 , WXGA |
| zobrazovací mód | AHVA, Normally Black, Transmissive |
| aktivní oblast | 107.64×172.224 mm |
| obrys | 114.6×184.6×3.85 mm |
| povrch | Glare (Haze 0%) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193158% |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4S5PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 36 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| B080EAN02.2 | AUO | 8.0 | 800×1280 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| LD080UX1-SMA2 | LG Display | 8.0 | 1200×1600 |
| PD080SL5 | E Ink | 8.0 | 800×600 |
| PD080SY1 | E Ink | 8.0 | 800×600 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HV121P01-100 | HYDIS | 12.1 | 1400×1050 |
| HV121WX6-111 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-110 | HYDIS | 12.1 | 1280×800 |
| LD070WU2-SM01 | LG Display | 7.0 | 1200×1920 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LQ079L1SX02 | SHARP | 7.9 | 1536×2048 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
