| PartNumber | LD070WU2-SM01 |
| Značka | LG Display |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 1200×1920 |
| Složení | LCM |
| Jas | 450 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | QLED |
| Rozhraní | MIPI |
| značka panelu | LG Display |
| panelový model | LD070WU2-SM01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 1200(RGB)×1920 , WUXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 94.5×151.2 mm |
| obrys | 104.52×161.87×2.4 mm |
| povrch | Hard coating |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4S6PQLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 40 pins |
| vstupní napětí | 3.7/1.8V (Typ.)(VSYS/VDD) |
| aplikace | PAD |
