| PartNumber | B116XAN03.1 HW0A |
| Značka | AUO |
| Velikost | 11.6 |
| aplikace | PAD |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 400 |
| CR | 800:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | AUO |
| panelový model | B116XAN03.1 HW0A |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 11.6 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | AHVA, Normally Black, Transmissive |
| aktivní oblast | 256.125×144 mm |
| obrys | 270.37×159.79×4.9 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193152% |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 10S3PWLEDEmbedded (LED Driver) |
| signálové rozhraní | MIPI (4 data lanes), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| B116XAN03.0 HW3A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW1A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116XW03 V1 | AUO | 11.6 | 1366×768 |
| N116B6-L04 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
| NT116WHM-N31 | BOE | 11.6 | 1366×768 |
| B070ATN02.0 | AUO | 7.0 | 600×1024 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| B080XAT01.1 | AUO | 7.9 | 768×1024 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| HJ101IA-01Q | Innolux | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| P120ZDG-BF2 | Innolux | 12.0 | 2160×1440 |
