| PartNumber | B070ATN02.0 |
| Značka | AUO |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 600×1024 |
| Složení | LCM |
| Jas | 400 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | AUO |
| panelový model | B070ATN02.0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 600(RGB)×1024 , WSVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 89.28×152.37 mm |
| obrys | 96.98×163.82×4.25 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 8 (Typ.)(Tr+Td) |
| úhel pohledu | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S6PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 32 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
