| PartNumber | B140QAN01.1 |
| Značka | AUO |
| Velikost | 14.0 |
| aplikace | NBPC |
| Rozlišení | 2560×1440 |
| Složení | LCM |
| Jas | 340 |
| CR | 700:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | AUO |
| panelový model | B140QAN01.1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 14.0 inch |
| rozlišení | 2560(RGB)×1440 , Quad-HD |
| zobrazovací mód | AHVA, Normally Black, Transmissive |
| aktivní oblast | 309.35×174.01 mm |
| obrys | 320.4×205.1×2.6 mm |
| tvarový styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| povrch | Antiglare, Hard coating (3H) |
| jas | 340 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | eDP (4 Lanes), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
