| PartNumber | B154EW02 V3 |
| Značka | AUO |
| Velikost | 15.4 |
| aplikace | NBPC |
| Rozlišení | 1280×800 |
| Složení | LCM |
| Jas | 220 |
| CR | 400:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | B154EW02 V3 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.4 inch |
| rozlišení | 1280(RGB)×800 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 331.2×207 mm |
| tvarový styl | Wedge (PCBA Bent, Depth ≥5.2mm) |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 220 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 4/12 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 6-bit), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| B154EW01 V3 | AUO | 15.4 | 1280×800 |
| B154EW01 V8 | AUO | 15.4 | 1280×800 |
| B154EW02 V0 | AUO | 15.4 | 1280×800 |
| B154EW02 V3 | AUO | 15.4 | 1280×800 |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| B154EW03 V1 | AUO | 15.4 | 1280×800 |
| B154EW08 V0 HW2A | AUO | 15.4 | 1280×800 |
| B154EW09 V0 | AUO | 15.4 | 1280×800 |
| B154EW09 V1 | AUO | 15.4 | 1280×800 |
| B154EW09 V2 | AUO | 15.4 | 1280×800 |
| B133XW07 V2 | AUO | 13.3 | 1366×768 |
| LP141X13-B1 | LG Display | 14.1 | 1024×768 |
| LP154W01-TLF1 | LG Display | 15.4 | 1280×800 |
| LP156WF1-TLC1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLF1 | LG Display | 15.6 | 1366×768 |
| LTD133EWDD | TOSHIBA | 13.3 | 1280×800 |
| LTN133AT01-001 | Samsung | 13.3 | 1280×800 |
| N121X5-L04 | Innolux | 12.1 | 1024×768 |
| N133HSE-EA1 | Innolux | 13.3 | 1920×1080 |
| TD141TGCD1 | TPO | 14.1 | 1024×768 |
