| PartNumber | N133HSE-EA1 |
| Značka | Innolux |
| Velikost | 13.3 |
| aplikace | NBPC |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 350 |
| CR | 700:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | eDP |
| značka panelu | CHIMEI INNOLUX |
| panelový model | N133HSE-EA1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 13.3 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | AAS, Normally Black, Transmissive |
| aktivní oblast | 293.76×165.24 mm |
| obrys | 305.35×192.82×3.07 mm |
| tvarový styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| povrch | Antiglare, Hard coating (3H) |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 14/11 (Typ.)(Tr/Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 9S6PWLEDEmbedded (LED Driver) |
| signálové rozhraní | eDP (2 Lanes), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| CLAA133UA03 | CPT | 13.3 | 1600×900 |
| LP133WH1-TLA1 | LG Display | 13.3 | 1366×768 |
| N133HSE-E21 | Innolux | 13.3 | 1920×1080 |
| N133HSE-EA1 | Innolux | 13.3 | 1920×1080 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
| N133HSE-EB1 | Innolux | 13.3 | 1920×1080 |
| N133HSE-EB2 | Innolux | 13.3 | 1920×1080 |
| N133HSE-EB3 | Innolux | 13.3 | 1920×1080 |
| N133HSG-WJ1 | Innolux | 13.3 | 1920×1080 |
| N133I6-L01 | Innolux | 13.3 | 1280×800 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| LP133WH2-TLM2 | LG Display | 13.3 | 1366×768 |
| LP140WH4-TLP1 | LG Display | 14.0 | 1366×768 |
| LP173WF3-SLB2 | LG Display | 17.3 | 1920×1080 |
| LTD121EWVB | TOSHIBA | 12.1 | 1280×800 |
| LTN140AT28-W01 | Samsung | 14.0 | 1366×768 |
| N141C3-L04 | Innolux | 14.1 | 1440×900 |
| N154I2-L01 | Innolux | 15.4 | 1280×800 |
| N156B3-L0A | Innolux | 15.6 | 1366×768 |
| N184H3-L02 | Innolux | 18.4 | 1920×1080 |
