| PartNumber | DLC0220BMG |
| Značka | Other |
| Velikost | 2.2 |
| aplikace | MPH |
| Rozlišení | 240×320 |
| Složení | LCM |
| Jas | 90 |
| CR | 120:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | DLC |
| panelový model | DLC0220BMG 2 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 2.2 inch |
| rozlišení | 240(RGB)×320 , QVGA |
| zobrazovací mód | ECB, Normally White, Transflective |
| aktivní oblast | 33.84×45.12 mm |
| obrys | 40.6×56.6 mm |
| povrch | Clear, Hard coating (3H) |
| jas | 90 cd/m² (Typ.) |
| kontrastní poměr | 120:1 (Typ.)(Transmissive) |
| zobrazit barvy | 262K (6-bit), CIE193130% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 40/45/48/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| vstupní napětí | 2.8V (Typ.)(VDD) |
| aplikace | MPH |
