| PartNumber | ACX450AKN-7 |
| Značka | JDI |
| Velikost | 5.0 |
| aplikace | MPH |
| Rozlišení | 1080×1920 |
| Složení | LCM |
| Jas | 485 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | JDI |
| panelový model | ACX450AKN-7 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 1080(RGB)×1920 , FHD |
| zobrazovací mód | Normally Black, Transmissive |
| aktivní oblast | 61.884×110.016 mm |
| obrys | 64.284×118.8×1.58 mm |
| povrch | Hard coating (3H) |
| jas | 485 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193171% |
| Doba odezvy | 35 (Max.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S2PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 31 pins |
| vstupní napětí | +5.0/-5.0/1.8V (Typ.)(AVDD+/AVDD-/IOVDD) |
| aplikace | MPH |
