| PartNumber | G104V1-T01 |
| Značka | Innolux |
| Velikost | 10.4 |
| aplikace | CNS |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 450 |
| CR | 1500:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | CMO |
| panelový model | G104V1-T01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | Super MVA, Normally Black, Transmissive |
| aktivní oblast | 211.2×158.4 mm |
| obrys | 225.5×176.3×10 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 1500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 14/9 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | CMOS/TTL (1 ch, 6-bit), 31 pins |
| vstupní napětí | 3.3/5.0V (Typ.)(VCC) |
| rohs: | |
| aplikace | CNS |
| AA104VH01 | Mitsubishi | 10.4 | 640×480 |
| AA104XG12 | Mitsubishi | 10.4 | 1024×768 |
| EL640.480-A4 SBS | PLANAR | 10.4 | 640×480 |
| G104V1-T01 | Innolux | 10.4 | 640×480 |
| G104V1-T03 | Innolux | 10.4 | 640×480 |
| G104VN01 V0 | AUO | 10.4 | 640×480 |
| G104VN01 V1 | AUO | 10.4 | 640×480 |
| G104X1-L04 | Innolux | 10.4 | 1024×768 |
| LQ104S1LG81 | SHARP | 10.4 | 800×600 |
| NL8060AC26-05 | NLT | 10.4 | 800×600 |
| 70WVW1A | SII | 7.0 | 800×480 |
| AC070MD01 | Mitsubishi | 7.0 | 800×480 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| LA060N01-SD01 | LG Display | 6.0 | 720×272 |
| LB070WV3-SD01 | LG Display | 7.0 | 800×480 |
| LQ064A5CG01 | SHARP | 6.4 | 480×234 |
| LQ065T5DG30 | SHARP | 6.5 | 400×240 |
| PW080XU1 | E Ink | 8.0 | 480×220 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
