| PartNumber | TM070WA-22L06 |
| Značka | SANYO |
| Velikost | 7.0 |
| aplikace | CNS |
| Rozlišení | 480×234 |
| Složení | LCM |
| Jas | 400 |
| CR | 100:1 |
| Barvy | |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | TORISAN |
| panelový model | TM070WA-22L06 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 480(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 154.08×87.05 mm |
| obrys | 167×102 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 100:1 (Min.) |
| zobrazit barvy | |
| Doba odezvy | 30/20 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/30/40 (Max.)(CR≥5)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFL |
| signálové rozhraní | TFT Specific Analog RGB, 24 pins |
| vstupní napětí | 5.3/15.0/-14V (Typ.)(VSH/VGH/VGL) |
| aplikace | CNS |
