| PartNumber | G173HW01 V0 |
| Značka | AUO |
| Velikost | 17.3 |
| aplikace | IA |
| Rozlišení | 1920×1080 |
| Složení | LCM |
| Jas | 400 |
| CR | 600:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | G173HW01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.3 inch |
| rozlišení | 1920(RGB)×1080 , FHD |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 381.888×214.812 mm |
| obrys | 403×240×13 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Doba odezvy | 37/3 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
