| PartNumber | AM480272H3TMQW-TW2H |
| Značka | AMPIRE |
| Velikost | 4.3 |
| aplikace | IA |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | 400 |
| CR | 250:1 |
| Barvy | 65K/262K |
| Podsvícení | WLED |
| Rozhraní | CPU |
| značka panelu | AMPIRE |
| panelový model | AM480272H3TMQW-TW2H |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.3 inch |
| rozlišení | 480(RGB)×272 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 95.04×53.856 mm |
| obrys | 105.5×67.2×7.91 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 250:1 (Typ.) |
| zobrazit barvy | 65K/262K |
| Doba odezvy | 15/35 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/35/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 7S1PWLEDWithout Driver |
| signálové rozhraní | 8/9/16/18-bit 6800/8080 parallel, 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
