| PartNumber | HB140WX1-500 |
| Značka | BOE |
| Velikost | 14.0 |
| aplikace | NBPC |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 200 |
| CR | 600:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | BOE |
| panelový model | HB140WX1-500 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 14.0 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 309.399×173.952 mm |
| obrys | 320.9×187.6×3 mm |
| tvarový styl | Slim (PCBA Flat, Depth ≤3.2mm) |
| povrch | Hard coating (3H) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 12 (Typ.)(Tr+Td) |
| úhel pohledu | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 9S4PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | NBPC |
| HB140WH1-504 | BOE | 14.0 | 1366×768 |
| HB140WX1-100 | BOE | 14.0 | 1366×768 |
| HB140WX1-200 | BOE | 14.0 | 1366×768 |
| HB140WX1-300 | BOE | 14.0 | 1366×768 |
| HB140WX1-301 | BOE | 14.0 | 1366×768 |
| HB140WX1-400 | BOE | 14.0 | 1366×768 |
| HB140WX1-401 | BOE | 14.0 | 1366×768 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| HB140WX1-501 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLD1 | LG Display | 14.0 | 1366×768 |
| B156XTN05.0 | AUO | 15.6 | 1366×768 |
| LP154WU1-TLB1 | LG Display | 15.4 | 1920×1200 |
| LP156WH2-TLF1 | LG Display | 15.6 | 1366×768 |
| LP171WU1-TLA5 | LG Display | 17.1 | 1920×1200 |
| LTN121X1-L02 | Samsung | 12.1 | 1024×768 |
| LTN133AT23-X01 | Samsung | 13.3 | 1366×768 |
| LTN141WD-L05 | Samsung | 14.1 | 1440×900 |
| LTN156AT30-W01 | Samsung | 15.6 | 1366×768 |
| LTN160AT01-W01 | Samsung | 16.0 | 1366×768 |
| N133BGE-L41 | Innolux | 13.3 | 1366×768 |
