| PartNumber | HSD170MGW1-B01 |
| Značka | HannStar |
| Velikost | 17.0 |
| aplikace | DMPC |
| Rozlišení | 1440×900 |
| Složení | LCM |
| Jas | 250 |
| CR | 600:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | HannStar |
| panelový model | HSD170MGW1-B01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1440(RGB)×900 , WXGA+ |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 367.2×229.5 mm |
| obrys | 389.2×254.5×11.8 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193163% |
| Doba odezvy | 3/5 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/65/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| B170PW06 V2 | AUO | 17.0 | 1440×900 |
| HSD170ME13-A04 | HannStar | 17.0 | 1280×1024 |
| HSD170ME13-A05 | HannStar | 17.0 | 1280×1024 |
| HSD170MGW1-A00 | HannStar | 17.0 | 1440×900 |
| HSD170MGW1-B00 | HannStar | 17.0 | 1440×900 |
| HSD170MGW1-B01 | HannStar | 17.0 | 1440×900 |
| L170E3 EC-5 | AUO | 17.0 | 1280×1024 |
| LTN170X2-L02 | Samsung | 17.0 | 1440×900 |
| M170EGE-L20 | Innolux | 17.0 | 1280×1024 |
| M170ETN01.1 | AUO | 17.0 | 1280×1024 |
| CLAA215FA01 | CPT | 21.5 | 1920×1080 |
| LM170E01-A6 | LG Display | 17.0 | 1280×1024 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LTM170E8-L03 | Samsung | 17.0 | 1280×1024 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| M220Z1-P03 | Innolux | 22.0 | 1680×1050 |
| M240HW01 V1 | AUO | 24.0 | 1920×1080 |
| M260J3-L01 | Innolux | 25.5 | 1920×1200 |
| M270HVN02.1 | AUO | 27.0 | 1920×1080 |
| MT190AW01 V.5 | Innolux | 19.0 | 1440×900 |
