| PartNumber | HT15X15-D01 |
| Značka | HYDIS |
| Velikost | 15.0 |
| aplikace | DMPC |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 400 |
| CR | 500:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | BOE HYDIS |
| panelový model | HT15X15-D01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.0 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 304.128×228.096 mm |
| obrys | 331.6×254.7×13 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193170% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | DMPC |
| AA150XN01 | Mitsubishi | 15.0 | 1024×768 |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| G150XGE-L04 | Innolux | 15.0 | 1024×768 |
| HT150X02-101 | BOE | 15.0 | 1024×768 |
| HT15X15-D01 | HYDIS | 15.0 | 1024×768 |
| HT15X23-100 | HYDIS | 15.0 | 1024×768 |
| HT15X31-100 | HYDIS | 15.0 | 1024×768 |
| LTM150XH-L04 | Samsung | 15.0 | 1024×768 |
| N150P2-L04 | IDTech | 15.0 | 1400×1050 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| L170E3 EC-5 | AUO | 17.0 | 1280×1024 |
| LC215DT4A | PANDA | 21.5 | 1920×1080 |
| LM200WD3-TLA1 | LG Display | 20.0 | 1600×900 |
| LM215DT1A | PANDA | 21.5 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LTM240CL01 | Samsung | 24.0 | 1920×1200 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| M185XW01 V8 | AUO | 18.5 | 1366×768 |
| M200HJJ-P01 | Innolux | 19.5 | 1920×1080 |
| NL10276AC30-03 | NLT | 15.0 | 1024×768 |
