| PartNumber | NL10276AC30-03 |
| Značka | NLT |
| Velikost | 15.0 |
| aplikace | DMPC |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 200 |
| CR | 200:1 |
| Barvy | Full color |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | NEC |
| panelový model | NL10276AC30-03 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.0 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 304.128×228.096 mm |
| obrys | 350×265×20.5 mm |
| povrch | |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 200:1 (Typ.) |
| zobrazit barvy | Full color , CIE193142% |
| Doba odezvy | 15/40 (Typ.)(Tr/Td) |
| úhel pohledu | 55/55/50/45 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 2 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | Analog RGB, 41 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | DMPC |
