| PartNumber | HV056WX1-100 |
| Značka | HYDIS |
| Velikost | 5.6 |
| aplikace | UMPC |
| Rozlišení | 1280×800 |
| Složení | LCM |
| Jas | 300 |
| CR | 500:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | BOE HYDIS |
| panelový model | HV056WX1-100 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.6 inch |
| rozlišení | 1280(RGB)×800 , WXGA |
| zobrazovací mód | HFFS, Normally Black, Transmissive |
| aktivní oblast | 120.96×75.6 mm |
| obrys | 131.7×87.7×5 mm |
| povrch | |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 8S2PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit), 25 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | UMPC |
