| PartNumber | AT056TN52 V.2 |
| Značka | Innolux |
| Velikost | 5.6 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 200 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | INNOLUX |
| panelový model | AT056TN52 V.2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.6 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 112.896×84.672 mm |
| obrys | 126.5×100 mm |
| povrch | Antiglare |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 3S6PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit), 50 pins |
| vstupní napětí | 3.3/5.0/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| aplikace | IA |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| AT056TN04 V.6 | Innolux | 5.6 | 320×234 |
| AT056TN52 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.2 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.3 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.4 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.5 | Innolux | 5.6 | 640×480 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| CLAA150XP06CW | CPT | 15.0 | 1024×768 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| HV121X02-100 | HYDIS | 12.1 | 1024×768 |
| LM12S472 | SHARP | 12.1 | 800×600 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| LQ130V3FZ20G | SHARP | 13.0 | 640×480 |
| LQ64D34 | SHARP | 6.4 | 640×480 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| SX25S004 | KOE | 10.0 | 800×600 |
| TX18D30VM2FAA | KOE | 7.0 | 800×480 |
