| PartNumber | HV070WS1-105 |
| Značka | HYDIS |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 1024×600 |
| Složení | LCM |
| Jas | 400 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | HYDIS |
| panelový model | HV070WS1-105 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 1024(RGB)×600 , WSVGA |
| zobrazovací mód | ADS, Normally Black, Transmissive |
| aktivní oblast | 153.6×90 mm |
| obrys | 163.6×102.9×2.67 mm |
| povrch | |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC) |
| Doba odezvy | 50 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S4PWLEDWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
