| PartNumber | KCG047QV1AA-A210 |
| Značka | Kyocera |
| Velikost | 4.7 |
| aplikace | IA |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 160 |
| CR | 30:1 |
| Barvy | Color |
| Podsvícení | CCFL |
| Rozhraní | Parallel Data |
| značka panelu | Kyocera |
| panelový model | KCG047QV1AA-A210 |
| typ panelu | CSTN-LCD , LCM |
| velikost panelu | 4.7 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | STN, Normally Black, Transmissive |
| aktivní oblast | 95.98×71.98 mm |
| obrys | 122.4×90×11.4 mm |
| povrch | Antiglare |
| jas | 160 cd/m² (Typ.) |
| kontrastní poměr | 30:1 (Typ.) |
| zobrazit barvy | Color |
| Doba odezvy | 490 (Typ.)(Tr+Td) |
| úhel pohledu | 50/50/15/35 (Typ.)(CR≥2)(L/R/U/D) |
| frekvence | 75Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| vstupní napětí | 3.3/5.0V (Typ.)(VDD) |
| aplikace | IA |
