| PartNumber | LD070WX3-SL01 |
| Značka | LG Display |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 800×1280 |
| Složení | LCM |
| Jas | 500 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | LG Display |
| panelový model | LD070WX3-SL01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 800(RGB)×1280 , WXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 94.2×150.72 mm |
| obrys | 104.32×161.67×3.84 mm |
| povrch | Hard coating |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Doba odezvy | 35 (Max.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5 stringsWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 34 pins |
| vstupní napětí | 3.3/1.8V (Typ.)(VDD/VCC) |
| aplikace | PAD |
| LD070WS2-SL01 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL02 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL03 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL04 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL05 | LG Display | 7.0 | 1024×600 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| LD070WU1-SM01 | LG Display | 7.0 | 1200×1920 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LD070WX3-SL01 | LG Display | 7.0 | 800×1280 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| HV121WX6-110 | HYDIS | 12.1 | 1280×800 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| N101BCG-L21 | Innolux | 10.1 | 1366×768 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
